Description
Overview
Integrated DSP ensures the PS15P can operate in any application
without complex external processing. A simple one-button high pass
filter switch rolls off low frequency material when PS15P is used with
any Paraline Series or powered élite System subwoofer. Bass boost
delivers remarkably improved bottom end response from the PS15P without
cluttering midrange program or affecting the cabinet’s overall
intelligibility – making it the perfect small speaker solution for
larger events where additional subwoofer support is not available.
Innovative multi-band limiting allows the cabinet to deliver maximum
output and remarkably event frequency response while protecting the
PS15P’s speaker components. Unlike competitive powered cabinets, the
Parasource Series multi-band limiting scheme ensures essential elements
like vocals and solo instruments in the essential midrange band aren’t
being modulated by transient attacks of low frequency material like kick
drums and bass tracks. This delivers an extremely smooth and precise
mix even at the highest output levels the cabinet can produce.
Designed for maximum versatility, the PS15P works equally well as a
Front-of House cabinet, side fill cabinet or floor monitor. Innovative
and highly efficient passive cooling scheme ensures the PS15P will
operate in any environment without need of noisy internal dust
collecting fans. Integrated reinforced flypoints ensure the PS15P can be
flown quickly and easily in any fixed installation.
Rugged yet lightweight ABS cabinet and baffle design ensure unmatched long term reliability in the field.
Specifications
| System Type | Active Loudspeaker |
| Active or Passive | Active |
| Program Power (Watts) | 1400 watts (4400 watts peak) |
| Max SPL (dB) | 134dB Peak (129dB Continuous) |
| Frequency Response (Hz +/- 3dB) | 45Hz to 26kHz |
| Crossover Frequency (Hz) | 1.0kHz |
| Driver Configuration | 15-inch / 1-inch |
| HF Driver(s) | 38mm Voicecoil w/ 1-inch Exit |
| HF Dispersion (°H x °V) | 85 x 50 |
| HF Protection | Thermal/Peak Limiter |
| LF Driver(s) | 15-inch (3 inch voicecoil) |
| LF Protection | Thermal/Multiband Peak Limiter |
| MF Processing | Dynamic Bass Extension |
| Cooling Scheme | Passive |
| Power Cable | Detachable IEC |
| Power Consumption (typ/max) | 2.4A/3.0A @ 120Vac 1.2/2.5 A @230Vac |
| Inputs | 1/4-inch, XLR, RCA |
| Inputs – 1/4″ Jacks | Yes (x2) |
| Inputs – XLR | Yes (x2) |
| Input Sensitivity (Vrms Sine) | 1.23 Vrms +4dBu |
| Mixer Controls | Sub Mode HPF, Bass Boost, Mixer Enable |
| Level Controls | Master Level, Mic Level, Line Level |
| LED Indicators | Power, Limit, Clip |
| Bar Handles | Yes |
| Flying Hardware | EYEBOLT1/4A |
| Pole Mount Adapter (1 3/8″-3.5cm) | Yes |
| Enclosure Materials | ABS |
| Baffle Material | ABS |
| Grille | Perforated Metal |
| Dimensions (DWH xbackW, inches) | 14.2 x 20.5 x 30.75 |
| Dimensions (DWH xbackW, cm) | 36.1 x 52.1 x 78.1 |
| Weight (lbs/kg) | 65 / 29.5 |
