Pioneer DJ XPRS122 12” full-range active loudspeaker

Description

XPRS122
12” full-range active loudspeaker

Versatile XPRSion

The XPRS2 Series couples the versatility and mobility of the original XPRS Series with elevated sound-performance and audio intelligibility to deliver a high-caliber speaker system for mobile DJs, live sound, houses of worship, rental and fixed installations.

KEY FEATURES
xprs2 series key feature 1
Powerful Class D Amplification

The XPRS2 Series employs Class D Amplification with high output wattage for a powerful and premiere audio experience for performers and listeners alike. The XPRS102 and XPRS122 full-range speakers feature Class D 2000 W amplification, while the XPRS1152S and XPRS1182S subwoofers offer Class D 4000 W amplification.

xprs2 series key feature 2
High Quality, Robust Build

Pioneer DJ’s all-new XPRS2 Series features a sleek all-black, protective pollywood cabinet for performance in harsh outdoor and indoor environments. The series models all come with a durable handle to support system portability and handling during setup and take down. The XPRS2 Series also features rubber feet to create separation and shock absorption between surfaces.

xprs2 series key feature 3
Four DSP Modes

Both of the XPRS2 full-range speakers contain four different DSP preset modes—Live, Music, Speech and Studio Monitoring—to address the needs of different listening environments.

xprs2 series key feature 9
16 Customizable User DSP Modes

In addition to the four presets, each XPRS2 full-range speaker includes 16 custom user DSP modes – which can be saved with different names – to ensure the EQ settings are maximized for every scenario.

xprs2 series key feature 5
Full-Range Speaker Design

The XPRS122 is the larger full range speaker counterpart in Pioneer DJ’s XPRS2 Series. Featuring a 12” woofer and 3” voice coil with a 1” exit compression driver and 1.75” voice coil, the speakers deliver comprehensive sound coverage across mid to large audiences and venues. Boasting a frequency response of 48 Hz – 20 kHz and a maximum SPL of 131 dB, the versatile full range speaker delivers powerful sound built to thrive in even the harshest of sound environments such as a live DJ set.
XPRS2 Series

Main Features
Type
    12 inch 2-way active loudspeaker
Amplifier Output


    Class D
    2000W peak

What’s in the Box


    XPRS122 x 1 (not sold as a pair)
    Powerd cord
    Quick start guide
    Important Safety Precautions

Specifications
Power supply
    110 V to 240 V (50 Hz/60 Hz)
Power consumption
    800 W
Frequency Range
    48 – 20000 Hz
Width
    362.7 mm
Height
    637 mm
Depth
    350 mm
Weight
    20.2 kg
System characteristic
DSP modes


    Factory Presets (4 types)
    Sub Setting (Sub Setting menu is for selecting the high-pass frequency or matching subwoofer)
    EQ (4-band equalizer)
    User Programs (16 presets)

DSP presets modes


    Factory presets
    LIVE
    MUSIC
    SPEECH
    MONITOR

Maximum Sound Pressure
    131 dB
Cross Over Frequency
    2 kHz
Terminals
Inputs


    MIC / LINE x 1 (Combo)
    HI-Z / LINE x 1 (Combo)
    3.5 mm stereo mini jack x 1 (Unbalanced input)

Outputs
    MIX (XLR)
Speaker
Driver


    12-inch ferrite LF cone driver
    1.75 inch compression driver

Finish
    Black paint, Rubber feet
Handle
    2 metal handles (on left side and top)
Pole socket
    35 mm socket
Rigging point
    10x M10
Enclosure
    Plywood (TSCA)
Protection
Amplifier Protection


    Thermal limiting
    Digital Limiter
    Digital compressor

Driver Protection
    Short circuit protection
Power unit Protection


    Primary AC mains overcurrent protection
    Primary AC mains overvoltage protection
