Product Description

KEY FEATURES
Brand-New Layout Design: Perform Intuitively
Artists are invited to get hands-on with an interface emulating two PLX turntables and a DJM-S series mixer – a common pro battle DJ setup.
• Battle-Style Setup
The DDJ-REV1 provides artists with space to perform mixing and scratching techniques with a new control arrangement. Tempo sliders are longer than sliders on the DDJ-SB3—measuring at 60mm— giving artists finer control. Sliders run horizontally above the decks while the Performance Pads are in the mixer section allowing artists to intuitively combine effects, trigger samples, and scratch tracks.
• Bigger Jog Wheels
Jog wheels on the DDJ-REV1 are the same size as jogwheels on the DDJ-SR2—a popular Pioneer DJ controller.
• Lever FX
Artists can dynamically add texture to their music with Lever FX in the mixer section, by pulling down the levers and holding them to apply effects from Serato DJ Lite in short bursts. Alternatively, artists can also push the levers up, to lock on effects and free their hands for scratching or track browsing.
Tracking Scratch: Get a Helping Hand with Scratching
The DDJ-REV1 helps artists have fun scratching without doing it all for them. Artists will still need to hone their skills, but the Tracking Scratch feature will silently take the music back to the cue point the moment they move the jog wheel backward or lift their hand away—in turn, saving them from needing to close the fader and find the right track place to start the scratch again. All artists need to do is select the Tracking Scratch Pad mode, press a Performance Pad to choose their desired Scratch Crossfader Cuts pattern and move the jog wheel.
Mixed Microphone Audio: Easily Add Voice While Streaming
For the first time in a Pioneer DJ controller at this level, the output of the master audio integrates with the microphone sound—removing the need for external equipment such as a soundcard or separate mixer. All sounds are sent to Serato DJ Lite so you can stream from there.
Serato DJ Lite Integration: Enjoy Full Use of the Free Software
After downloading Serato DJ Lite to their PC/Mac for free, artists connect the DDJ-REV1 via the supplied USB cable and begin DJing. Artists enjoy tactile control of various features and effects in the software by manipulating the controller’s buttons, knobs, faders and jog wheels.
With Scratch Bank pad mode, artists instantly load scratch samples from four banks that they’ve assigned in Serato DJ Lite or Pro by simply tapping the dedicated Scratch Bank button. Artists can load from a specific start point too – handy if they want to use this feature to drop in full tracks during a routine.
Other Features
• Deck 3/4 Control: Play tracks and sounds loaded on any of the four Serato DJ Lite decks.
• Serato DJ Pro Support: Elevate performances with a 14 day free trial of Serato DJ Pro. (Paid
Permanent Upgrade Available Separately)

DDJ-REV1 SPECIFICATIONS
Software
Total Harmonic Distortion
Input / Output Terminals
Inputs
Serato DJ Lite
Serato DJ Pro (license/subscription not included)


Frequency Response
   20Hz – 20kHz

S/N Ratio

103 dB(USB)

0.005 %

MIC x 1 (1/4” TS jack)

Power Consumption
Outputs
MASTER x 1 (RCA x 1)

USB
PHONES x 1 (3.5-mm stereo mini jack x 1)
USB Type-B x 1
       Power Supply
USB Type-B bus powered

5V 500mA

526.0 × 255.5 × 59.2 mm / 20.7” × 10.06” × 2.33”
   Maximum Dimensions (W x D x H)

Weight
2.1 kg / 4.6 lbs.

Accessories
USB cable
Warranty (for some regions) Quick Start Guide Precautions for Use
