Chauvet DJ GigBAR Bridge Beam ILS 3-in-1 moving head beam lighting system RGBW

Description

GigBAR Bridge Beam ILS

3-in-1 lighting system that includes moving heads, RGBW
rings and washes pre-mounted on a single bar
Quickly and securely connect multiple fixtures with the
built-in locking system
Built-in DFI transceiver communicates DMX or ILS signals
wirelessly
ILS compatibility for use in the ILS ecosystem
Safely mounts onto truss or mobile tripods using the
removable bracket
Easy navigation and access all functions directly from
the full-color LCD display
Totem Mode keeps the moving heads focused on the
dance floor
Save time running cables and extension cords by power
linking multiple units
Use the included RF remote to trigger the built-in shows
without needing line of sight

Specifications
DMX Channels: 3, 24 or 60
DMX Connectors: 3-pin XLR
Pan and Tilt: 540°/270°
Pan and Tilt Ranges: 180° 360° 540° Pan / 90° 180° 270° tilt
Light Source (moving heads): 2 LEDs (RGBW) 80 W total
(2.8 A), 50,000 hours life expectancy
Light Source (wash): 4 LEDs (RGBAW+UV) 40 W total (2.6 A),
50,000 hours life expectancy
Light Source (LED ring): 48 LEDs (RGBW) 10 W total 50,000
hours life expectancy
Strobe Rate: 0 to 20 Hz
PWM Frequency: 1200 Hz
Beam Angle (moving head): 5°
Beam Angle (wash): 20°
Field Angle (wash): 37°
Operating Frequency: 2.4 GHz
Illuminance (moving head) : 24,670 @ 2 m (per head)
Illuminance (wash) : 525 Lux @ 2 m (per section)
Max Unobstructed Distance (D-Fi): 600 ft (183 m)
Power Linking: 9 units @120 V; 18 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 147 W, 1.2 A 120 V, 60 Hz
Power and Current: 144 W, 0.6 A 230 V, 50 Hz
Fits Tripod Sizes: 1.5 in (37.4 mm)
Approvals: CE, RoHS, FCC
