ADJ Focus Spot 6Z 300W LED Moving Head
ADJ Focus Spot 6Z 300W LED Moving Head - Image 2
ADJ Focus Spot 6Z 300W LED Moving Head - Image 3
ADJ Focus Spot 6Z 300W LED Moving Head - Image 4
ADJ Focus Spot 6Z 300W LED Moving Head - Image 5
ADJ Focus Spot 6Z 300W LED Moving Head - Image 6

ADJ

ADJ Focus Spot 6Z 300W LED Moving Head

$2,999.99

Free Shipping
More on the way soon!


-

Contact us for exact availability - 1-888-621-DJDJ (3535)
Or send us an email
SKU: FOC635 Category: Brand:

Description

The Focus Spot 6Z is powered by a brilliant 300W cool white LED
engine that produces vibrant, saturated colors and is equipped with
motorized focus, zoom (9~28-degree zoom), Iris and two prisms. It is
designed for temporary live events and fixed installations in
nightclubs, stages or churches. It is professionally fit with two GOBO
wheels (7 GOBOs per wheel), two COLOR wheels, each with 7 vibrant colors
plus white, and 2 rotating/indexable prisms, (one 6-facet linear and
one 6-facet circular). It also has two frost effects (heavy frost and
light frost).

The Focus Spot 6Z has locking
power In and out connectors to daisy chain the power, as well as 3-pin
and 5-pin DMX In/Out to transmit a DMX signal from one fixture to the
next. It also has RJ45 In/Out connections to control with ArtNet and
KlingNet. There is a USB firmware update port built-in plus advanced
control options such as: 16-bit fine pan and tilt, multiple DMX control
modes, and 6 different dimming options. The Focus Spot 6Z offers a
robust light output in a light weight, compact foot print (18-inch high
and one 23 pounds).



Specifications

Light Source:

• 300W Cool White LED Engine (50,000 hr.)
Features:
• Motorized Focus
• 2 Frost Filter to create wash effects
• Motorized Zoom: 9~28-degrees
• 2 Prism FX: Rotating 6-facet Linear & rotating 6-facet Circular
• Motorized Iris
• Motorized Shutter
• 0-100% smooth dimming
• Various strobe speeds
• USB firmware update port
Color Wheels:
• Color Wheel 1: 7 dichroic colors + white
• Color Wheel 1: 7 dichroic colors (includes CTO, CTB and UV filters)
GOBO Wheels:
• GOBO Wheel 1: 7 GOBOS + open
• GOBO Wheel 2: 7 GOBOS + open
• GOBO Shake Effect
Prism Wheel:
• Prism Wheel 1: Rotatable 6-facet Linear
• Prism Wheel 2: Rotatable 6-facet Circular
• Each Prism is indexable
Frost Filters:
• Frost 1: Heavy frost for wash effect
• Frost 2: Light frost creates lightly blurred edges for GOBO and Prism FX
 Control:
• 2 DMX Channel Modes: 22/25 Channels
• Color LCD display with 6-button function menu
• Control Mode: DMX512 or internal programs
• 6 Dimming Curve Modes: Standard, Stage, TV, Architectural, Theatre, Stage 2
• 0-100% smooth dimming
• Various strobe speeds
• USB firmware update port
• With Wired Digital Communication Network

Pan/Tilt:
• Pan: 630 degrees
• Tilt: 270 degrees
• 16-bit fine Pan & Tilt
Connections:
• DMX Connections: 3-pin & 5-pin XLR In/Out
• Power Connections: PowerLock In/Out to daisy chain power
• RJ45 In/Out connections for ArtNet and KlingNet
Electrical:
• Multi-voltage operation: AC 90-240V, 50/60Hz
• Max power consumption: 380W
Dimensions & Weight:
• Dimensions (LxWxH): 7.6” x 11” x 18” / 195x278x457mm
• Weight: 23 lbs. / 10.4 kg.
