ADJ Focus Spot 4Z Pearl – 200W LED Moving Head w/ Motorized Focus & Zoom

$1,649.99

Free Shipping
In Stock Online - ETA 5-7 Days or Less!


-

Contact us for exact availability 1-888-621-DJDJ (3535)
Or sendus an email
SKU: FOC225 Category: Brand:

Description

American DJ FOCUS SPOT 4Z Pearl Overview

The black American DJ Focus Spot 4Z
is a 200W moving-head spot fixture with motorized focus and zoom, well
suited for lighting installations and live performance applications in
clubs, theaters, and concert productions. The 4Z features a 200W
cool-white LED engine (rated at 50,000 hours), 16-bit fine tilt and pan
movement, 16-bit fine dimming resolution, motorized focus, and a
motorized zoom from 11 to 22°.

The color wheel has eight colors plus white and six replaceable rotating
GOBOs plus open. Additional features include two prism effects
including rotating 5-facet linear and rotating 6-facet circular. This
fixture features six selectable dimming curves as well as numerous
built-in effects.

For controls, the unit features several DMX
channel modes with 3-pin XLR DMX input and output connectors. Multiple
units can be daisy-chained to create complex lighting installations. The
color display on the front panel shows DMX addressing and function
settings, controllable via the four-button interface. A dedicated USB
port is available for firmware updates.

  • 200W cool-white LED engine (50,000 hours)
  • 8 colors + white
  • 6 rotating, replaceable GOBOs + open
  • Zoom range: 11 to 22°
  • Focus: motorized
  • 2 prism FX: rotating 5-facet linear and rotating 6-facet circular
  • powerCON in/out to daisy-chain power
  • 3-pin DMX in/out
  • USB firmware update port
  • Multiple DMX control channels mode
  • Fine pan & tilt: 16-bit
  • Dimming & fine dimming (16-bit): 0-100% electronic
  • 6 dimming modes: standard

American DJ FOCUS SPOT 4Z Specs

Light Source

 200 W Cool-White LED
Life Expectancy

 Approximately 50,000 Hours
Beam Angle

 11 to 22°
Zoom

 Motorized
Pan & Tilt

 Standard and Fine Control
Movement Resolution

 8-bit / 16-bit
Color Wheel

 8 Colors + Cool White
Gobos

 6 Rotating and Replaceable GOBOs + Open
Focus

 Motorized
Prism

 Prism 1: 5-Facet Linear, Rotating
Prism 2: 6-Facet Circular, Rotating
Dimming

 Type: Electronic Standard and Fine (16-Bit)
Range: 0-100%
Dimmer Curves

 6 Curves
Protocols

 DMX
DMX Connectors

 Input 1 x XLR 3-Pin
Output: 1 x XLR 3-Pin
DMX Channel Modes

 Multiple Channel Modes
Power Connector

 Input/Ouput: powerCON
Input Voltage

 100 to 230 VAC, 50/60 Hz
Dimensions

 17.7 x 11.0 x 6.9″ / 448.8 x 279.4 x 174.0 mm
Weight

 18.3 lb / 8.3 kg
