Product Description

Ape Labs is known to be “Tiny but Mighty”. The original Ape Labs Coin took that to the next level, weighing in at only about a half-pound, and still packing a powerful punch!

The Coin 2.0 IP ups the ante signicantly, as it comes in at the same size, but is more than 2x the brightness of the previos generation Coin. It is extremely versatile as all of the Can 2.0 accessories fit on the Coin 2.0. The Coin 2.0 is essentially the Can 2.0, but without the battery. This reduces the size and reduces the price. It’s perfect for installations and mobile set-ups that don’t need battery….or it can be easily converted into a battery fixture by adding a USB battery bank. Simply plug one, two, or three Coin 2.0’s into a standard USB battery bank and you’ll be totally wireless, just like the Can 2.0!

Plus, the new AmberWhite LED technology allows color for reproduction that was never possible before. With 29 built-in color presets designed specifically for the event industry by industry professionals, the Coin 2.0 allows the user to create incredible lighting designs with just the push of a button. Crafted in Germany with a careful balance of totally reengineered optics merged with the warmth of the AmberWhite LED technology, the Coin 2.0 is an incredibly flexible fixture, excellent for uplighting, unique Fresnel effect uplighting, ambient lighting, dance floor lighting, stage lighting, design washes, table lighting, pin spotting, room washing, tube effects, and beyond.

    1x 15 Watt RGBaW with AmberWhite LED Technology (Now 2.27x Brighter at Same Wattage)
    Single Color LUX as high as 3,460 @1m (see table below)
    Refreshed optics for optimal brightness without sacrificing battery life (when used with battery bank)
    Standard with Fresnel Effect Lens. Available Par Wash Optics: 10°, 15°, 25°, & 45°
    2.27x brightness of previous generation Can, 82% as bright as original Maxi (45 Watts)
    USB Powered. Any standard USB port will work, including a USB battery bank
    Solid State, Fanless operation
    29 carefully curated color presets designed for weddings & events
    IP65 Rated for Indoor or Outdoor Use
    Free standing or mountable via M6 Thread
    For version with built-in battery, Check out the Can 2.0
    PWM (LED refresh rate) adjustable via smartphone app (500Hz to 4000Hz)
    Compatible with smartphone app via Connect hardware
    100% Designed, Engineered, & Hand Assembled in Germany

Control / Operation:

Ape Labs is known to “Keep it Simple” when it comes to controlling lights. A beginner with no instructions can typically operate an Ape Labs fixture within seconds of picking up an ApeRemote or opening the app. But its simplicity does not lack in features. Two of the most famous features are “Grouping” and “MusikMode”.

Grouping allows the user to create DMX-Like shows on the fly by grouping any number of mixed & matched Ape Labs SKUs on up to four groups. Then being able to control groups individually or universally.

MusikMode will automatically create a music-based light show with the press of a button. It uses proprietary technology that analyzes the sound in the room and total number of Ape Labs fixtures to build a constantly evolving light show. Just don’t call it “Sound Active”.

    Wireless DMX: 4, 7, or 8 Channel Modes (W-App / Connect required, 3900ft Range)
    Wireless KNX (W-App / Connect required, 3900ft Range)
    Wireless Android / iOS App (W-App / Connect required, 3900ft Range)
    Wireless Remote Control (ApeRemote required, 200ft Range)

    Wireless range increases as more fixtures are added since all lights repeat the signal
    Pairing is possible with ApeRemotes or W-Apps to increase number of groups or universes in the room
    Ape Labs Connect will save settings and programs to the cloud for cross device operations or community sharing
    Free software/firmware updates via W-App or Connect

Specs:

    Powered via USB cable
    Made from stainless steel
    wavelength red = 622.5nm
    wavelength green = 522.5nm
    wavelength blue = 457.5nm
    AmberWhite Color Temperature = 2700K
    Color rendering in CRI (Ra) = 90
    PWM (Pulse Width Modulation) = 500Hz – 4000Hz
    flicker free = Yes
    Dimmable = Yes
    Total lamp luminous flux = 545 lm

Photometric Data:

When comparing Ape Labs LUX values to competitor values, make sure to look at single color ratings. If only a single LUX value is given for a fixture, it’s most likely an “All On” rating. This means that every color is combined when rating.

The Ape Labs Coin 2.0 IP comes standard with 65° Effect Lens, but four alternative optics are available. Below are the LUX ratings for each color, with each beam angle, at both 1m and 2m distances.
Color     aW     aW     R     R     G     G     B     B
Distance     1m     2m     1m     2m     1m     2m     1m     2m
10°     1,770     545     1,790     515     2,300     933     3,460     809
15°     1,503     402     1,400     355     2,290     422     2,970     712
25°     565     126     455     100     602     133     1,004     215
45°     272     73     242     64     319     101     522     170
65° FX     125     31     87     23     130     38     177     48

**With 15 degree wash optics, the Coin 2.0 LUX ratings average 227% (or 2.27x brighter) than the original Coin @2m

Dimensions Coin 2.0: 1.5 x 2.4in
Weight: 0.55 lbs
