Highlights

Compact LED effect light projects multicolored rotating gobos

Create mid-air effects and blanket the room with ever-changing patterns

Separate color and gobo wheels allow for creative programming

Generate a synchronized show in Master/Slave mode with built-in automated programs

Compatible with IRC-6 for flexible control over all features

Save time running cables and extension cords by power linking multiple units

Multiple control options include stand-alone, DMX, IR or master/slave

Fits best in the CHS-40 VIP Gear Bag

Specifications
DMX Channels: 7
DMX Connectors: 3-pin XLR
Colors: 13 + white, split colors, continuous scroll at variable speeds
Gobos: 14 (metal) + open, continuous scroll at variable speeds
Light Source: 1 LED (cool white) 60 W, (2.25 A), 50,000 hours life expectancy
Strobe Rate: 0 to 20 Hz
PWM Frequency: 4 KHz
Power Linking: 8 units @ 120 V; 14 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 70 W, 1 A @ 120 V, 60 Hz
70 W, 0.5 A @ 230 V, 50 Hz
Weight: 5.6 lb (2.6 kg)
Size: 12.6 x 8.26 x 8.26 in (320 x 210 x 210 mm)
Approvals: CE
Optional Controllers: IRC-6
What’s Included
Obsession
Power cord
Quick Reference Guide
